Solar PoE Station-18W

Solar PoE Station-18W

Designed to provide power to PoE devices with limited access to electrical utilities. The Solar PoE Station-18W has built in Power over Ethernet (PoE) and available integrated Wireless LTE Connectivity. Powered by an industry leading 36 AH battery, it expands the possibilities of your PoE device solutions.

View full details

Specifications

Hardware

  • 120W/36V Monocrystalline Solar Panel
  • (1) LiFePO₄ Batteries 25.6V/36AH
  • PoE Switch: 2 Ports IEEE802.3af/at @PoE+ or 1 Port IEEE802.3af/at @PoE+ , and 1 Port 24v/0.5A@PoE
  • Housed in Powder Coated Die-cast Aluminum Housing and Extruded Aluminum Frame
  • Two Year Warranty
  • Dark Grey Pantone 8403C finishing
  • IP 66/IK 08 Except Solar Panel IK07
  • Spigot Diameter: 2 3/8 in. Pole-top Tenon

Electrical

  • System Voltage: 24V
  • System Power Capabilities: 18 Peak Watts
  • 8-9 hour charge time during peak sunshine

Environmental

  • Charge Temperature: 32° F ~ 131° F | 0° C ~ 55° C
  • Discharge Temperature: -7° F ~ 140° F | -20° C ~ 60
  • Storage Temperature: 32° F ~ 113° F | 0℃~ 45℃
  • EPA Rating: 6.67

Packaging

  • Solar PoE Station Dimensions (in.): 60.6x15.7x5.4
  • Package Dimension (in.): 64.8x19x10
  • Net Weight (±0.5lbs): 53
  • Gross Weight (±0.5lbs): 62.2

Accessories

  • EP-SOL-MOUNT-RP 5 in Round Pole Bracket for Single Solar Station
  • EP-SOL-MOUNT- 90 90 Degree Bracket for 6x6 Wood Post

Documents

Spec Sheet

Operation Manual

Data Plan Account Activation
